21/25

(21. /or/ex lightbox)

(probably) Hitachi H8/300 compatible CPU: Nikon DSB01/on the left, above the ocular (metering chip): /Sony/415PO/ILX141N/all the connections from the top LCD and the matrix metering chip seem to go to the IC on top of the camera (top of the image)
